HIKMICRO Mini3

Product Code:

Mini3

Warranty Period:

Contact us

Infrared Image

IR Resolution

384×288 (110,592 pixels)

NETD (Thermal Sensitivity)

≤35 mK (@ 25 °C, F#=1.0)

Image Frequency

25Hz/50Hz (if you want to enable 50Hz, you need 8 GB RAM or more on mobile devices)

Detector Curtain

12 microns

Spectral Range

7,5 ila 14 μm

Focal Length

10mm

F-number

F1.0

Field of View (FOV)

26° × 19°

Focus Mode

Manual Focus

Min. Focal Length

0,3 m (0,98 ft)

Image Display

Image Modes

Termal

Colour Palettes

White Hot, Black Hot, Rainbow, Iron Spring, Sepia, Colourful, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue, Combined

Measurement and Analysis

Object Temperature Range

Range -20℃ to 150℃（-4°F to 302°F) Range 100℃ to 650℃（212°F to 1202°F）

Certainty

Maximum (±2°C/3.6°F, ±2%) for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)

Measurement Tools

Centre Point, Hot Point, Cold Point can be defined by the user: 3 points and 3 rectangles.

Level and Scope Mode

Automatic/Manual
