HIKMICRO HM-TD2037T-10/X

Product Code:

HM-TD2037T-10/X

Warranty Period:

Contact us

Thermal Module

Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Pixel Pitch

17 μm

Thermal Sensitivity (NETD)

< 35 mK (25 °C, F# = 1,0)

Spatial Resolution (IFOV)

1.75 mrad

Field of View

37,5° × 28,5° (Y x D)

Min. Focus Distance

1.5 meters

Aperture Range

F1.0

Spectral Range

8 μm to 14 μm

Focal Length

9,7 mm

Resolution

384 × 288

Measurement and Analysis

Object Temperature Range

-20 °C to 150 °C (-4 °F to 302 °F), 0°C to 550 °C (32 °F to 1022 °F)

Measurement Presets

Real-time hot spot, cold spot

Point

10 User Presets

Liner

1 User Presets

Area

7 User Presets

Color Alarm (Isotherm)

Above/Between/Below

Temperature Accuracy

Maximum (± 2 °C, ± 2%)

Thermographic Integration

Temperature Metadata

Continuous output data of preset thermographic rules and measured temperature

Thermographic Data Coding

4 fps, 32 bit 384×288 per frame

Thermographic Data Upload

Real-time full-screen thermographic data matrix (16-bit or 32-bit 384×288) via RTSP, ISAPI and SDK

Raw Data Loading

Real-time full-screen YUV data via RTSP and SDK

Video and Image

Ana Akım

50 frames per second (384 × 288)

Video Compression

H.265/H.264/MJPEG

Color Palettes

H.265/H.264/MJPEG 15 options: White Hot, Black Hot, Fusion 1, Rainbow, Fusion 2, Iron Spring 1, Iron Spring 2, Speia, Color 1, Color 2, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue

Digital Zoom

×2, ×4, ×8

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, ISUP

Simultaneous Live View

Up to 3 channels

User/Host level

Up to 32 users, 3 levels: Administrator, Operator, User

Security

User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering

Customer

HIKMICRO Studio

Interface

Communication Interface

1, RJ45 10M/100M self-adaptive Ethernet interface 1, RS-485 interface (ModBus is available)

Alarm Input

1, alarm input (0-3.3 VDC)

Alarm Output

1, alarm output; NC, level amount

Analog Output

1, CVBS output
