HIKMICRO Eco

Product Code:

Eco

Warranty Period:

Contact us

Infrared Image

IR Resolution

96 × 96 (9,216 pixels)

NETD (Thermal Sensitivity)

< 50 mK (@ 25 °C, F#=1.0)

Image Frequency

25 Hz

Detector Curtain

12 mikron

Spectral Range

7,5 ila 14 μm

Focal Length

1,35 mm

F-number

F1.0

Field of View (FOV)

50° × 50°

Spatial Resolution (IFOV)

8.89 mrad

Focusing

Fixed

Min. Focal Length

0.1 m (0.33 ft)

Image Display

Screen

240 × 320 Resolution, 2.4’ LCD Display

Image Modes

Thermal

Colour Palettes

White Hot, Black Hot, Rainbow, Iron Spring, Red Hot, Fusion

Colour Alarm

Alarm above

Measurement and Analysis

Object Temperature Range

Range -20°C to 150°C (-4°F to 302°F) , Range 100℃ to 550℃ (212°F to 1022°F)

Certainty

Maximum (±2°C/3.6°F, ±2%) when ambient temperature is above 25°C (77°F) and object temperature is above 0°C (32°F)

Measurement Tools

Centre Point, Hot Spot, Cold Spot

Level and Scope Mode

Automatic/Manual

Veri Depolama ve İletişim

Depolama Ortamı

Dahili 4 GB flash bellek

Görüntü Depolama Kapasitesi

Yaklaşık 30.000 Görüntü
