HIKMICRO Eco-V

Product Code:

Eco-V

Warranty Period:

Contact us

Infrared Image

IR Resolution

96 × 96 (9,216 pixels)

NETD (Thermal Sensitivity)

< 50 mK (@ 25 °C, F#=1.0)

Image Frequency

25 Hz

Detector Curtain

12 mikron

Spectral Range

7,5 ila 14 μm

Focal Length

1,35 mm

F-number

F1.0

Field of View (FOV)

50° × 50°

Spatial Resolution (IFOV)

8.89 mrad

Focusing

Fixed

Min. Focal Length

0,1 m (0,33 ft)

Image Display

Visual Camera

640 × 480

Screen

240 × 320 Resolution, 2.4’ LCD Display

Image Modes

Thermal/Visual/Fusion

Colour Palettes

White Hot, Black Hot, Rainbow, Iron Spring, Red Hot, Fusion

Colour Alarm

Alarm above

Measurement and Analysis

Object Temperature Range

Range -20°C to 150°C (-4°F to 302°F) , Range 100℃ to 550℃ (212°F to 1022°F)

Certainty

Maximum (±2°C/3.6°F, ±2%) when ambient temperature is above 25°C (77°F) and object temperature is above 0°C (32°F)

Measurement Tools

Centre Point, Hot Spot, Cold Spot

Level and Scope Mode

Automatic/Manual

Data Storage and Communication

Storage Media

Built-in 4G eMMC (the storage space available to the user is less than the nominal capacity)

Image Storage Capacity

Approximately 18,000 images
