HIKMICRO Mini2 V2

Product Code:

Mini2 V2

Warranty Period:

Contact us

Infrared Image

IR Resolution

256 × 192 (49,152 pixels)

NETD (Thermal Sensitivity)

< 40 mK (@ 25 °C, F#=1.0)

Image Frequency

25 Hz

Detector Curtain

12 mikron

Spectral Range

7,5 ila 14 μm

Focal Length

3,5 mm

F-number

F1.0

Field of View (FOV)

50° × 37,2°

Focusing

Fixed

Min. Focal Length

0,2 m (0,66 ft)

SuperIR

Yeah, I've got a visual on the captured footage and the live feed.

Image Display

Image Modes

Thermal, PIP

Colour Palettes

White Hot, Black Hot, Rainbow, Iron Spring, Sepia, Colourful, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue, Combined

Measurement and Analysis

Nesne Sıcaklık Aralığı

Range -20℃ to 150℃（-4°F to 302°F） Range 100℃ to 400℃（212°F to 752°F）

Object Temperature Range

Maximum (±2°C/3.6°F, ±2%) for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)

Measurement Tools

Centre Point, Hot Point, Cold Point can be defined by the user: 3 points, 3 rectangles and 1 line.

Level and Scope Mode

Automatic/Manual
