HIKMICRO MiniE

Ürün Kodu:

MiniE

Garanti Süresi:

Bize Ulaşın

Infrared Resolution

96 × 96 (9, 216 pixels)

NETD (Thermal Sensitivity)

< 50 mK (@ 25 °C, F#=1.0)

Image Scanning Speed

25 Hz

Detector Curtain

12 microns

Spectral Range

7.5 to 14 μm

Focal Length

1,35 mm

F-number

F1.0

FOV (Field of View)

50° × 50°

Focusing

Fixed

SuperIR

Yeah, I've got a visual on the captured footage and the live feed.

Min. Focal Length

0,1 m (0,33 ft)

Screen

Image Modes

Termal, PIP

Colour Palettes

White Hot, Black Hot, Rainbow, Iron Spring, Sepia, Colour, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue, Combined, Custom Palette

Measurement and Analysis

Object Temperature Range

Range -20℃ to 150℃（-4°F to 302°F） Range 100℃ to 400℃（212°F to 752°F）

Certainty

Maximum (±2°C/3.6°F, ±2%) for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)

Measurement Tools

Centre Point, Hot Point, Cold Point can be defined by the user: 3 points, 3 rectangles and 1 line.

Level and Scope Mode

Automatic/Manual
